Analysis of the Effect of Vehicle Load on Road Layer Damage on Alluvial Bedrock Using PCI and ESAL Approaches: A Case Study of Air Molek–Taluk Kuantan Road, Riau Province, Indonesia

Bustanul Ulum; Elizar; Mohammad  Syahminan

doi:10.25299/jgeet.2025.10.3.23740

Authors

Bustanul Ulum Master of Civil Engineering, Programme of Post Graduate, Universitas Islam Riau, 28284, Indonesia.
Elizar Master of Civil Engineering, Programme of Post Graduate, Universitas Islam Riau, 28284, Indonesia.
Mohammad Syahminan Master of Civil Engineering, Programme of Post Graduate, Universitas Islam Riau, 28284, Indonesia.

DOI:

https://doi.org/10.25299/jgeet.2025.10.3.23740

Keywords:

Road Damage, Vehicle Load, Soft Soil, Peatland, PCI, ESAL

Abstract

The Molek-Taluk Kuantan Air Road in Indragiri Hulu Regency, Riau, has suffered a lot of damage due to frequent crossings by heavily loaded vehicles. This study aims to find out how much the vehicle load affects the damage to the road, as well as see how soil conditions and the shape of the area contribute to the worsening of the damage. The assessment was carried out using the PCI (Pavement Condition Index) method to see the level of physical damage to the road, and the ESAL (Equivalent Single Axle Load) method to calculate the vehicle load. The observation results show that the number of vehicles passing by reaches more than 4,000 per day, with a high overload rate (Truck Factor = 3.93). In addition, the soil structure in this region consists of soft soils such as clay and peatlands, which are very susceptible to damage if constantly subjected to heavy loads. The area through which the road passes also has a slope that can cause erosion and soil shift. Overall, the average road condition was in the damaged category (PCI value = 37.4). The results of this study show the need to repair roads that take into account soil conditions, strengthening drainage, and limiting vehicle loads so that damage does not continue to recur.

Downloads

Download data is not yet available.

References

AASHTO. (1993). Guide for Design of Pavement Structures. Washington DC: American Association of State Highway and Transportation Officials.

ASTM. (2007). Standard Practice for Roads and Parking Lots Pavement Condition Index Surveys (ASTM D6433-11).WestConshohocken,PA:ASTM International.

Barber, A. J., Crow, M. J., & Milsom, J. S. (2005). Sumatra: Geology, Resources and Tectonic Evolution (Geological Society Memoir No. 31). London: Geological Society of London.

Bell, F. G. (2004). Engineering Geology. Elsevier Butterworth-Heinemann.

Bowles, J. E. (1997). Foundation Analysis and Design (5th ed.). McGraw-Hill..

Das, B. M. (2010). Principles of Geotechnical Engineering (7th ed.). Cengage Learning.

FHWA. (2011). Distress Identification Manual for the Long-Term Pavement Performance Program. Federal Highway Administration, U.S. Department of Transportation.

Gaillot, P., Rachmat, H., & Sani, M. F. (2023). High heat flow in Central Sumatra Basin: Implications for geothermal energy. Renewable Energy Geoscience Journal, 12(4), 345–360.

Government of the Republic of Indonesia. (2006). Government Regulation Number 34 of 2006 concerning Roads. Jakarta: State Secretariat

Huang, Y. H. (2004). Pavement Analysis and Design (2nd ed.). Pearson Prentice Hall.

Kausarian, H., Masdriyanto, S., Batara, B., & Suryadi, A. (2023a). Geomorphological and geological studies using Digital Elevation Model (DEM) data in the Kampar Regency Watershed area, Riau Province. Journal of Geoscience, Engineering, Environment, and Technology, 8.

Koesoemadinata, R. P. (1980). Stratigrafi Indonesia. Bandung: Institut Teknologi Bandung Press

Mitchell, J. K., & Soga, K. (2005). Fundamentals of Soil Behavior (3rd ed.). John Wiley & Sons.

Sukirman, S., 2010. Perencanaan Tebal Struktur Perkerasan Lentur. Nova.

Terzaghi, K., Peck, R. B., & Mesri, G. (1996). Soil Mechanics in Engineering Practice (3rd ed.). Wiley.

Utama, H. W., Ritonga, D. M., & Kurniantoro, E. K. (2021). Geodynamic relationship of Sabak back-arc volcanics and Geragai geothermal features, Jambi, Indonesia. In Proceedings of the 3rd Green Development International Conference (pp. 376–382)

Van Bemmelen, R. W. (1949). The Geology of Indonesia, Vol. IA. Government Printing Office, The Hague.

Van Zuidam, R. A. (1985). Aerial photo-interpretation in terrain analysis and geomorphologic mapping. ITC Publication No. 6. Enschede, The Netherlands: International Institute for Aerospace Survey and Earth Sciences

Verstappen, H. T. (1983). Applied Geomorphology: Geomorphological Surveys for Environmental Development. Elsevier.
