Evaluation of Gas Lift Deepening Design Using a Retrofit Gas Lift System to Increase Well Production in an Offshore Field: Case Study of Well S-7
DOI:
https://doi.org/10.25299/jgeet.2025.10.1.1.24189Keywords:
Gas Lift, Retrofit Gas Lift, Horizontal Well, Well Modelling, Nodal AnalysisAbstract
S-7 well is a horizontal well in the NDF Field that produces hydrocarbons from carbonate formation for over seven years using gas lift. Over time, S-7 well has experienced a significant decline in production due to reservoir pressure along with an increase in water cut. To address this issue, a well intervention was conducted to deepen the injection point by installing Retrofit Gas Lift technology, aiming to enhance the well's production to an optimal level. This research focuses on evaluating the application of Gas Lift Deepening using Retrofit Gas Lift (RGL) in Well S-7 through well modeling methods with PROSPER software and providing recommendations for an optimal Gas Lift Deepening design. The study analyzes well modeling for Well S-7 before and after RGL installation, validated using well test data to compare production performance in both scenarios. The evaluation proceeds by identifying the parameters that influence the effectiveness of the Retrofit Gas Lift (RGL), followed by designing an optimized RGL system to enhance production performance. Based on the research, the installation of the Retrofit Gas Lift (RGL) in Well S-7 resulted in an increase in the production rate of 78.58 STB/d. Sensitivity testing identified key factors influencing the production rate, including reservoir pressure, top node pressure, gas injection rate, coil tubing size, and coil tubing length. Design optimization by adjusting the top node pressure to 130 psi, coiled tubing length to 2000 ft, coiled tubing size to 1.75 in, and gas lift injection rate to 1 MMSCFD resulted in an increased flow rate of 220.86 STB/d and a drawdown of 751.77 psi.
Downloads
References
Al-Arbi Ganat, T., Asante Otchere, D., Ganat, T.A., Ridzuan, P.D.K., Lashari, M.N., Oun, M.M. and Ali, M.I. (2020) ‘Develop optimum gas lift methods to improve gas lift efficiency using gas lift pack-off, deep gas lift, and deep lift set’, International Journal of Advanced Research in Engineering and Technology, 11, pp. 1096–1114. doi:10.34218/IJARET.11.11.2020.100
Beggs, H.D. (2003) Production optimization using nodal analysis. 2nd edn. Oklahoma: OGCI and PetroSkills Publications.
Bellarby, J. (2009) ‘Artificial lift’, in Developments in Petroleum Science, Vol. 55. Elsevier, pp. 225–276. doi:10.1016/S0376-7361(08)00206-9
Chia, Y.C. and Hussain, S. (1999) ‘Gas lift optimization efforts and challenges’, Proceedings of the SPE Asia Pacific Improved Oil Recovery Conference. SPE-57313-MS. doi:10.2118/57313-MS
de Souza, J.N.M., de Medeiros, J.L., Costa, A.L.H. and Nunes, G.C. (2010) ‘Modeling, simulation and optimization of continuous gas lift systems for deepwater offshore petroleum production’, Journal of Petroleum Science and Engineering, 72, pp. 277–289. doi:10.1016/j.petrol.2010.03.028
Djabaruddin, A., Purwoko, K., Andriyanto, E. and Yusim, S. (2016) ‘Retrofit gas lift system: An unconventional method to maximize hydrocarbon recovery’, Proceedings of the Indonesian Petroleum Association 40th Annual Convention and Exhibition, Jakarta.
Guo, B., Liu, X. and Tan, X. (2017) Petroleum production engineering: A computer-assisted approach. Oxford: Elsevier Science & Technology.
Guo, B., Lyons, W.C. and Ghalambor, A. (2007) Petroleum production engineering: A computer-assisted approach. Houston, TX: Gulf Professional Publishing. doi:10.1016/B978-0-7506-8270-1.X5000-2
Khairun Nissa, Z. and Sudibjo, R. (2015) ‘Retrofit gas lift: A practical solution to increase production’, Proceedings of the Seminar Nasional Cendekiawan.
Mehran, F. (2022) ‘Artificial lift experience in Malaysia and Indonesia and the way forward’, Journal of Petroleum Technology. doi:10.2118/0622-0038-JPT
Shobar, M.R.C., Widarena, T., Trimaharika, W., Muhroni, T.O. and Handoko, B.S. (2019) ‘Integrating gas lift well optimization from well model to field-scale network to assess additional compressor impact’, Proceedings of the Joint Convention Yogyakarta, Yogyakarta.
Syarafi Ashfahani, A., Wijaya, G.L., Krishna, A., Wijaya, R., Mahardhini, A. and Kusuma, D.H. (2018) ‘Gas lift technology guidance for better decision making based on 40 years proven implementation for Handil Field, Delta Mahakam’, Proceedings of the Indonesian Petroleum Association 42nd Annual Convention and Exhibition, Jakarta.
