Analysis of the Factor of Safety (FS) in Slope Stability Against Blasting Activities at Pit X, South Kalimantan

Muhammad Mufty Zaki Sahya; Misbahuddin

doi:10.25299/jgeet.2025.10.1.1.24084

Authors

Muhammad Mufty Zaki Sahya Universitas Pertamina, Department of Geological Engineering
Misbahuddin Universitas Pertamina, Department of Geological Engineering

DOI:

https://doi.org/10.25299/jgeet.2025.10.1.1.24084

Keywords:

Slope stability, Safety Factor, Blasting, Pit Mining, South Kalimantan

Abstract

Blasting is used to break hard rock in mining, but the vibrations can destabilize the slope through the resulting soil vibrations. The resulting blasting vibration must be in a safe condition, especially the stability of the mine slope around the blasting. This study aims to analyze the value of the slope factor of safety (FS), blasting soil vibration, and the influence of soil vibration on the value of the factor of safety (FS). The research method involves data collection followed by slope stability analysis utilizing the Bishop Simplified Method within Slide software and blasting vibration analysis using regression models to determine Maximum Horizontal Acceleration (Amax). The study results showed that the value of FS varied based on location and geological conditions. The A-A' section in the upper western part of the mine has the highest FS value of 2.36, while the C-C' cross-section in the lower eastern part of the mine has the lowest FS value of 1.16. Analysis of soil tremors in Amax values showed the highest values in August and the lowest at the end of October. The Amax value has an effect on the decrease in the FS value based on the blasting distance. The B-B' cross-section has the largest influence, the A-A' and C-C' cross-sections have a fairly small influence, and the D-D' cross-section has no influence.

Downloads

Download data is not yet available.

References

Agnesty, I., Purwoko, B. and Meilasari, F., 2018. Kajian biaya peledakan pada proses pembongkaran batuan granit di PT Hansindo Mineral Persada. JeLAST: Jurnal PWK, Laut, Sipil, Tambang.

Amaliya, N., Mardiah, M. and Akuan, A., 2016. Pengaruh getaran tanah akibat peledakan terhadap kemantapan lereng Tambang Air Laya Selatan PT Bukit Asam (Persero) Tbk. MINERAL, 1(1), pp.67–75. doi:10.33019/mineral.v1i1.1612.

Bowles, J.E., 1989. Sifat-Sifat dan Geoteknis Tanah. Jakarta: Erlangga.

Canima, D. and Heriyadi, B., 2019. Analisis penentuan batas aman ground vibration akibat kegiatan peledakan terhadap kestabilan lereng highwall penambangan Pit 13 West PT Multi Harapan Utama, Samarinda, Kalimantan Timur. Bina Tambang, 4(4), pp.24–38.

Das, B.M. and Sivakugan, N., 2017. Fundamentals of Geotechnical Engineering. Cengage Learning.

Frank, L.J., 2003. Tight Construction Blasting: Ground Vibration Basics, Monitoring, and Prediction.

Heryanto, R., 2010. Geologi Cekungan Barito, Kalimantan. Bandung: Badan Geologi Kementerian Energi dan Sumber Daya Mineral.

Heryanto, R. and Sanyoto, P., 2007. Peta Geologi Lembar Amuntai, Kalimantan, Skala 1:250.000. Bandung: Center of Research and Development of Geology.

Hoek, E. and Bray, J.D., 1981. Rock Slope Engineering. CRC Press. doi:10.1201/9781482267099.

Hoek, E. and Brown, C., 2002. Hoek-Brown failure criterion — 2002 edition. In: Proceedings of NARMS-Tac. Rocscience.

Mahda, D. and Yuliadi, 2022. Analisis pengaruh getaran peledakan terhadap kestabilan lereng pada PT XYZ Blok Paniisan. Jurnal Riset Teknik Pertambangan, pp.125–132. doi:10.29313/jrtp.v2i2.1317.

Pratiwi, I.Y., Cahyono, Y.D.G. and Putri, F.A.R., 2022. Evaluasi dampak getaran tanah terhadap aktivitas peledakan di Pit TSBC PT Bukit Asam Tbk. Prosiding Seminar Nasional Sains dan Teknologi Terapan.

Tsiambaos, G. and Saroglou, H., 2010. Excavatability assessment of rock masses using the Geological Strength Index (GSI). Bulletin of Engineering Geology and the Environment, 69, pp.13–27. doi:10.1007/s10064-009-0235-9.

Wang, I.T., 2019. Field experiments and numerical analysis of the ground vibration isolation of shock wave propagation under explosion shock loading. Vibration, 2, pp.300–310. doi:10.3390/vibration2040019.
